AC Current Voltage Amperage Power Energy Panel Meter LCD Digital Display Ammeter Voltmeter Multimeter with Split Core Current Transformer CT AC 80-260V 100A Multi-Function Power Monitor

A.Main Function 1. Electrical parameter measurement function (voltage current active power energy frequency power factor) 2. Overload alarm function (over power alarm threshold backlight and power flashing to alarm). 3. Power alarm threshold preset function (can set power alarm threshold). 4. The energy can be reset use the key. 5. Store data when power off. 6. Large-screen LCD 7. Backlight function. B. Appearance and Key function Display interface is large-screen LCD it can display six parameters at the same time. 1. Power: test range: 0~22000W Starting measure power: 0.5W 2. Energy: test range: 0~999kWh 3. Voltage: test range: 80~260V 4. Current: test range: 0~100A Starting measure current: 0.02A 5. Frequency: test range: 45~65Hz 6. Power factor: test range: 0~1PF C.Specification parameters 1. Working voltage: 80 ~ 260VAC 2. Test voltage: 80 ~ 260VAC 3. Rated power: 100A/22000W 4. Operating frequency: 45-65Hz 5. Measurement accuracy: 1.0 grade
