BOJACK 45+5uF 45/5MFD ±6% 370V CBB65 Dual Run Circular Start Capacitor for AC Motor Run or Fan Start or Condenser Straight

BOJACK Dual run circular start capacitor Ombines two capacitors into one unit. Three terminals on the top are labeled ""Herm""/""H"" for the compressor motor ""Fan""/""F"" for the fan and ""C"" for the common line.It will power a compressor motor and a fan motor Model: CBB65（Universal model） Shell material: metal Dielectric Material: metallized polypropylene film Capacity: 45+5uf Tolerance: ±6% Rated voltage: 370V AC Frequency: 50 / 60Hz Safety rated: 10 000 AFC Capacitor dimension: Diameter(50 mm/1.97 inch) Height(95 mm/3.74 inch) Operating temperature: -40 ℃ to +70℃ This capacitor is used for start-up and operation of AC motors with frequency of 50Hz/60Hz such as Industrial Grade Replacement for Central Air-Conditioners Heat Pumps Condenser Fan Motors and Compressors. It is small in size lightweight heat resisting and anti-explosion.
